Jimmy Page EDS-1275 Doubleneck VOS Specifications
Body Style
SG
Body Shape
EDS-1275
Body Material
One Piece Mahogany
Binding
Single-ply, Fretboards
Body Finish
Nitrocellulose VOS
Profile
Jimmy Page EDS-1275
Scale Length
628.65 mm / 24.75 in
Fingerboard Material
Indian Rosewood
Fingerboard Radius
304.8 mm / 12 in
Neck Material
Mahogany
Fret Count
20
Frets
Authentic Medium Jumbo
Nut Material
Corian
Nut Width
42.8625 mm / 1.687 in
Inlays
Aged Cellulose Nitrate Parallelogram
Joint
Long Tenon, Hide Glue Fit
Finish
Chrome
Bridge
True Historic ABR-1
Saddle Material
Nickel
Tailpiece
Chrome 6/12 EDS-1275
Tuning Machines
Kluson Double Line, Double Ring with Keystone Button
Pickguard
Jimmy Page EDS-1275
Truss Rod
Adjustable
Truss Rod Cover
3-ply Black with Vertical "Custom" Hot Stamp
Control Knobs
Black Speed with Dial Pointer
Switch Tip
Cream
Control Covers
Black
Strap Buttons
2 - Bottom and Behind 12-String Neck Heel
Mounting Rings
Black
Pickup Covers
12-String Pickups: True Historic Chrome, 6-String Pickups: None
Neck Pickup
Jimmy Page EDS-1275 Custombuckers, Double Black Bobbins, Alnico 5
Bridge Pickup
Jimmy Page EDS-1275 Custombuckers, Double Black Bobbins, Alnico 5
Controls
2 Volume, 2 Tone; Hand-wired with CTS Potentiometers and Period-correct Ceramic Disc Capacitors
Pickup Selector
3-way Switchcraft plus 3-way Switchcraft Neck Select Switch
Output Jack
1/4" Switchcraft
Strings Gauge
6-String Neck: .010, .013, .017, .026, .036, .046; 12-String Neck: 010, .014, .024, .009, .030, .012, .040, .018, .048, .0.28
Case
Hardshell Case
Accessories
Vintage Leather Strap and a Certificate of Authenticity with a Photo from Photographer Barrie Wentzell
ギブソンは製品デザイン・クオリティ・快適な演奏性の実現に向け絶えず改善に努め、常に最良のマテリアルを製品に取り入れられるよう、製品の予告なき仕様変更を行うことがあります。
