Warren Haynes Les Paul Standard Specifications
Body Style
Les Paul
Body Shape
Les Paul
Body Material
Mahogany
Top
Maple
Binding
Single Ply, Top and Fretboard
Body Finish
Gloss Nitrocellulose Lacquer
Weight Relief
None
Profile
50s Vintage
Scale Length
628.65 mm / 24.75 in
Fingerboard Material
Indian Rosewood
Fingerboard Radius
304.8 mm / 12 in
Neck Material
Mahogany
Fret Count
22
Frets
Medium Jumbo
Nut Material
Graph Tech
Nut Width
43.053 mm / 1.695 in
End Of Board Width
57.404 mm / 2.26 in
Inlays
Acrylic Trapezoid
Joint
Glued In, Set Neck
Finish
Nickel
Bridge
ABR-1
Tailpiece
Aluminum Stop Bar
Tuning Machines
Vintage Deluxe with Keystone Button
Pickguard
Cream
Truss Rod
Adsjustable
Control Knobs
Gold Top Hat with Dial Pointer
Switch Tip
Amber
Switch washer
Cream
Jack Plate Cover
Cream
Strap Buttons
2
Pickup Covers
Cream P-90 Soapbar
Neck Pickup
P-90 DC Soapbar
Bridge Pickup
P-90 DC Soapbar
Controls
2 Volume, 2 Tone, Mini Toggle for +15 dB Boost; Hand-wired with Orange Drop Tone Capacitors
Pickup Selector
3-way Toggle
Output Jack
1/4"
Preamp
15 dB Boost Circuit (9V Battery Compartment Mounted on Control Plate on Rear)
Strings Gauge
.010, .013, .017, .026, .036, .046
Case
Hardshell
Accessories
Includes Gibson Accessory Kit
ギブソンは製品デザイン・クオリティ・快適な演奏性の実現に向け絶えず改善に努め、常に最良のマテリアルを製品に取り入れられるよう、製品の予告なき仕様変更を行うことがあります。
