Volante Quilt HHFR Specifications
Body Style
Double Cut
Body Shape
Volante
Body Material
Alder
Top
AAAA Quilt Maple Veneer
Body Finish
Gloss Body, Satin Neck
Profile
Kramer Elliptical C
Scale Length
647.7 mm / 25.5 in
Fingerboard Material
Ebony
Fingerboard Radius
Compound
Neck Material
3-piece Laminated Maple; Thermally Aged
Neck Finish
Natural Satin
Fret Count
24
Frets
Jumbo
Nut Material
Floyd Rose R3 Locking; Rear Mounted
Nut Width
42.86 mm / 1.687 in
Inlays
Mother of Pearl Diamond
Joint
Bolt On with Ferrules and Kramer Keylock System
Finish
Black
Bridge
Floyd Rose 1000 Series; Recessed
Tuning Machines
Mini Die Cast
Pickguard
3-Ply Black/White/Black
Truss Rod
Dual Action
Control Knobs
Black Knurled Metal Dome
Switch Tip
Black
Control Covers
Black
Strap Buttons
2 - Black Nickel; Bottom and Upper Horn
Pickup Covers
None
Neck Pickup
Kramer USA Neptune R Humbucker
Bridge Pickup
Kramer USA Neptune T Humbucker
Controls
Master Volume, Master Tone
Pickup Selector
5-way Blade Switch
Output Jack
1/4" Barrel Jack
Strings Gauge
.009, .011, .016, .024, .032, .042
Case
Premium Gig Bag
Accessories
Floyd Rose Wrench Holder on Headstock Rear
Disclaimer: In order to continually improve the design, quality and performance of our products and instruments and to make use of the best materials at all times, Kramer reserves the right to change specifications without notice.
